D3PlotViewer

D3Plot is part of the Oasys suite of software by Arup and allows users to view the output of LS-Dyna simulations such as the effect of seismic activity on buildings, car crashes, explosions, fluid dynamics and glass shattering.

D3PlotViewer is an online viewer which allows anyone to view GLB files exported from D3Plot in the browser without any additional dependencies. It has the ability to show cut sections, animations, contour plots and annotations for multiple models at once.
I have been working on improving the shading of D3PlotViewer, bringing it closer to the shading in D3Plot and am currently working on bringing Physically Based Rendering to D3PV for compelling photorealistic results. Most recently, I have been working on D3Plot to include the ability to export multiple lighting states including intensity and direction of lights which are viewable in the online viewer.
D3Plot Desktop Software
Virtual Garage demo in D3Plotviewer
touchscreen virtual garage demo shown at the Oasys LS-DYNA 2024 conference in Birmingham
touchscreen virtual garage demo shown at the Oasys LS-DYNA 2024 conference in Birmingham
Oasys LS-DYNA 2024 conference at the Hyatt Regency hotel in Birmingham
Oasys LS-DYNA 2024 conference at the Hyatt Regency hotel in Birmingham
